Tolleranze Dimensionali per Accoppiamenti Meccanici


ALBERO/FORO
UNI 6388 ISO R.286
c13/C13
c13
mm 1 ÷ 3= -0,060/-0,200
mm 3 ÷ 6=-0,070/-0,250
mm 6 ÷ 10=-0,080/-0,300
mm 10 ÷ 18=-0,095/-0,365
mm 18 ÷ 30=-0,110/-0,440
mm 30 ÷ 40=-0,120/-0,510
mm 40 ÷ 50=-0,130/-0,520
mm 50 ÷ 65=-0,140/-0,600
mm 65 ÷ 80=-0,150/-0,610
mm 80 ÷ 100= -0,170/-0,710
mm 100 ÷ 120= -0,180/-0,600
mm 120 ÷ 140= -0,200/-0,830
mm 140 ÷ 160=-0,210/-0,840
mm 160 ÷ 180=-0,230/-0,860
mm 180 ÷ 200=-0,240/-0,960
mm 200 ÷ 225=-0,260/-0,980
mm 225 ÷ 250=-0,280/-1,000
mm 250 ÷ 280=-0,300/-1,110
mm 280 ÷ 315=-0,330/-1,140
mm 315 ÷ 355=-0,360/-1,250
mm 355 ÷ 400=-0,400/-1,290
mm 400 ÷ 450=-0,440/-1,410
mm 450 ÷ 500=-0,480/-1,450
mm 1 ÷ 3=+0,200/+0,060
mm 3 ÷ 6=+0,250/+0,070
mm 6 ÷ 10=+0,300/+0,080
mm 10 ÷ 18=+0,365/+0,095
mm 18 ÷ 30=+0,440/+0,110
mm 30 ÷ 40=+0,510/+0,120
mm 40 ÷ 50=+0,520/+0,130
mm 50 ÷ 65=+0,600/+0,140
mm 65 ÷ 80=+0,610/+0,150
mm 80 ÷ 100= +0,710/+0,170
mm 100 ÷ 120= +0,600/+0,180
mm 120 ÷ 140= +0,830/+0,200
mm 140 ÷ 160=+0,840/+0,210
mm 160 ÷ 180=+0,860/+0,230
mm 180 ÷ 200=+0,960/+0,240
mm 200 ÷ 225=+0,980/+0,260
mm 225 ÷ 250=+1,000/+0,280
mm 250 ÷ 280=+1,110/+0,300
mm 280 ÷ 315=+1,140/+0,330
mm 315 ÷ 355=+1,250/+0,360
mm 355 ÷ 400=+1,290/+0,400
mm 400 ÷ 450=+1,410/+0,440
mm 450 ÷ 500= +1,450/+0,480
